Manure Dehydrator Cleaning Machine



Manure Dehydrator Cleaning Machine:

"The Manure Dehydrator Cleaning Machine is primarily used for separating solid and liquid components from poultry and pig manure. This machine goes by several names such as manure processor, manure separator, manure dehydrator, and poultry manure cleaning machine.

"This machine, also known as a livestock and poultry manure dehydrator, can effectively separate raw manure water from pig, duck, cow, chicken, and other poultry and livestock manure into liquid and solid fertilizers. The liquid fertilizer can be directly utilized for crops, while the solid fertilizer can be transported to areas lacking fertilizer, aiding in soil structure improvement. Additionally, it can be used to produce compound fertilizer through fermentation. Raw manure water is fed into the machine via a mud pump, where solid matter is extruded and separated by the screw shaft within the screen, with the liquid flowing out through the liquid outlet."

"It is not only suitable for separating manure but also for separating residues and liquids from high-concentration organic wastewater. These include livestock manure, slaughter sewage, paper pulp, crop residues, food residues, distiller grains, and biogas residues."





Model	SL150	SL200	SL280	SL350
Capacity(m3/h)	8-10	15-20	25-30	35-40
Main Power(kW)	4	5.5	7.5	11
Pump Power(kW)	3	4	5.5	5.5
Screen Inner Dimension(mm)	150*460	200*460	280*460	350*800
Main Motor Speed(r/min)	43	43	43	43
Pump Speed(r/min)	1450	1450	1450	1450
Weight(kg)	350	480	700	1200
Dimension(mm)	2000*500*1600	2100*600*1600	2200*700*1650	2800*1600*1700
Voltage	380v 50hz(can be changed as customers' request)
Material	The outer shell is iron steel, inner contact parts are stainless steel 304



"The Manure Dehydrator Cleaning Machine uses a non-blocking slurry pump to transfer the manure to the main machine, where an extrusion screw auger pushes it forward. The moisture in the material is squeezed out through the mesh screen under the pressure of the side pressure belt filter, and the water is discharged through the water pipe. As this process continues, the pressure in front of the main machine gradually increases. Once it reaches a certain level, the discharge port opens, allowing the extrusion port to expel the squeezed material, achieving the purpose of extrusion and discharge."









Q: What services do you offer?
A: We offer excellent quality machinery, advanced technology, and outstanding service.

Q: What are your warranty terms?
A: We offer different warranty times for different products. Please contact us for detailed warranty terms.

Q: What is the advantage of your company?
A: Our company has a professional team and a professional production line.

Q: Could you provide us with a better price?
A: Of course, we can provide you with an accurate quotation based on your specific requirements and order volume.



Hot Tags: manure dehydrator cleaning machine, China manure dehydrator cleaning machine manufacturers, suppliers
