Products Description
The candy packaging machine is composed of a conveying system, a film supply system, a former, a sealing system, a cutting device, a control system, and an electric eye tracking system.
Products Parameter
|
Model |
TZ-250 |
TZ-320 |
TZ-350 |
TZ-450 |
TZ-600 |
|
Film Width |
Max 250 mm |
Max 320mm |
Max 350mm |
Max 450mm |
Max 600mm |
|
Bag Length |
45-220 mm |
120-280mm |
120~280mm |
130-450mm |
120-450mm |
|
Bag Width |
30-110 mm |
50-160mm |
50~160mm |
50-180mm |
50-180mm |
|
Product Height |
Max.40 mm |
Max.60mm |
Max. 60mm |
Max.70mm |
Max.70mm |
|
Capacity |
40-330 bag/min |
40-230 bag/min |
40-230 bag/min |
30-180 bag/min |
30-180 bag/min |
|
Power |
2.4 kW |
2.6 kW |
2.6 kW |
2.6 kW |
3.6kw |
|
Weight |
800 kg |
900 kg |
900 kg |
900 kg |
960kg |
|
Dimension |
3770*670*1450 mm |
3770*720*1450 mm |
4020*745*1450 mm |
4020*820*1450 mm |
4380*970*1500 mm |
|
note |
be able to customize |
||||
Working Principle
When the staff prepares the candy to be packaged, they are gradually brought into the packaging area through the conveyor belt. At this time, the plastic film enters the packaging host through the film supply mechanism. After the induction control system detects that an object has entered the packaging area, the film is sent to the former to form a bag. After the product enters the bag, the heat sealing device heat-seals both sides of the film to form a sealed packaging bag. The continuous bagging of the candy packaging machine production line is cut into independent packages according to the preset length by the cutting device, and then the finished product is brought into the next process for stacking through the cutting device, or it is used with the cartoning machine for cartoning and packaging.
Products Features
1. The candy packaging machine uses a CNC panel, and the computer screen controls the whole machine, which is easier to operate and equipped with a fault alarm and fault detection function
2. Multi-directional sealing molds can adjust the angle at will, suitable for various roll film materials, and the sealing effect is smoother and more beautiful
3. The sealing mold protection cover is installed to protect the operator and increase safety, prevent foreign objects from entering the machine, and avoid accidental damage
4. The candy packaging machine has a linked film roll shaft, synchronous film feeding, smoother packaging and sealing, and can be equipped with a coding machine and inkjet printer
Why Choose Us
1. With strong corporate strength and rich experience, we have been focusing on the R&D, design, production and manufacturing of automatic packaging machinery and equipment for more than ten years as a comprehensive service provider.
2. Production standardization to ensure product quality, 6S control at the production site, strict control and implementation of various indicators, equipped with advanced testing equipment, strict implementation of testing indicators to ensure product quality.
3. Large-scale mass production, timely supply, fast delivery, complete quasi-spot supply categories, standardized mass production with short delivery time.
