Industrial Coffee Roasting Machine





The industrial coffee roasting machine uses a far-infrared ceramic inner pot. The surface of the inner pot is made of plasma-sprayed far-infrared ceramic. The far-infrared rays emitted can directly penetrate the coffee beans for heating. The inner and outer ceramic coatings provide an extra layer of protection for the coffee beans, even under high-power roasting conditions. The ceramic layer can also effectively isolate harmful high temperatures, reduce the burnt bitterness produced during roasting, and restore the flavor of the coffee itself.



1. Roast raw coffee beans in a roasting barrel and cool them in a cooling tray.
2. Start the industrial coffee roasting machine, run the baking barrel, run the hot air fan, turn on the fire button, and preheat the machine. During the preheating stage, the heater heats the baking barrel and the air at the same time, and then introduces the hot air into the baking barrel.
3. After reaching the predetermined preheating temperature, the coffee beans enter the roasting barrel from the feeding hopper. The roasting barrel and hot air work together to heat the green coffee beans until they reach the end of roasting temperature.
4. When the roasting end temperature is about to be reached, start the cooling plate, cooling fan, and stirrer.
5. Manually pour the coffee beans into the cooling plate, stir with a stirrer, and use a cooling fan to cool the coffee beans.
6. After cooling is completed, open the bean outlet to pour out the coffee beans, and close the cooling plate bean outlet.
7. The roasting stage and cooling stage can be carried out at the same time.





1. The industrial coffee roasting machine adopted semi-direct fire and semi-hot air roasting type
2. Cast iron inner pot, heated evenly
3. Safety control system, ultra-high temperature protection.
4. Heat-resistant fireproof brick insulation layer, high thermal efficiency utilization.
5. High-power fan, rapid cooling, locking in flavor.
6. Continuously adjust the damper to freely control the exhaust volume.
7. Equipped with raw and cooked bean feeders to facilitate loading and unloading.
8. Temperature curve output software application (optional)



Model	Capacity	Size(mm)	Net weight
TZ-020	1.0kg/batch	1060*780*1210	120kgs
TZ-030	2.0kg/batch	1100/800/1400	140kgs
TZ-040	3.0kg/batch	1100/800/1400	150kgs
TZ-060	6.0kg/batch	1520*960*1490	220kgs
TZ-100	10kg/batch	1700*1100*1850	410kgs
TZ-150	15kg/batch	1800*1100*2000	385kgs
TZ-200	20kg/batch	1950*1100*1950	450kgs
TZ-300	30kg/batch	2650*1500*2400	850kgs
