Products Description

1. Wheel mill mixer, the disc is fixed on the vertical shaft, and it is driven to rotate by the motor after being decelerated by a reducer, a pulley and a pair of bevel gears.
2. There are two grinding wheels on the grinding plate, which are respectively movably sleeved on the horizontal shaft. The two ends of the horizontal shaft are supported on two bearings in the side brackets, and the middle part is movably sleeved on the vertical shaft. The housing of the bearing can slide up and down along the guide groove in the side bracket, so the height of the drum can be automatically adjusted up and down.
3. The material entering the machine is sent to the bottom of the roller by the scraper mounted on the beam for repeated crushing. Due to the centrifugal force and rolling effect, the crushed materials are thrown to the sieve plate of the outer ring of the grinding plate, and the qualified materials leak into the arc-shaped groove on the fixed chassis and then are scraped to the discharge port by the discharge scraper rotating together with the grinding plate unloaded.
4. Unqualified materials are sent to the bottom of the roller by the feeding scraper on the screen surface for further crushing. The particle size of the product can be controlled by adjusting the size of the sieve hole and the amount of feeding material.

Wheel mill mixer

Products application

Wheel mill mixer, applied to mixing solid material and liquid material, widely applied in various kinds of forming production lines. It is a kind of ideal mixing equipment that can be easily used in the chemical industry, light industry, building materials, and other industries mixing with powder materials.

Wheel mill mixer

product-750-804

Products details

Wheel mill mixer

Products parameters

Model	Disk diameter(mm)	Add the amount each time(kg)	Capacity(kg/h)	Motor Power(kw)
wood-1100	1100	100	400-500	5.5
wood-1300	1300	150	500-800	5.5
wood-1500	1500	200	800-1000	7.5
wood-1800	1800	300	1000-1200	15

Products Features

Advantage:

High efficiency: The charcoal mill can quickly process a large amount of materials, improve production efficiency, and reduce costs.

Quality Control: They ensure that the quality of the final product is consistent, consistent, and meets customer requirements.

Environmentally friendly: Charcoal mills are often designed to be energy efficient, while also processing waste and renewable resources, helping the environment.

Versatile: They are suitable for many different types of carbonized materials with flexibility.
