Mealworm Screening Machine

The mealworm screening machine absorbs dust during the entire screening process to prevent the dust from filling the air and harming the operator's health (long-term inhalation of dust can cause rhinitis, pneumonia, bronchitis, pneumoconiosis, lung cancer... etc. Using the machine is for health!). All functions of this machine can be divided into two parts:
1. All functions include: selecting pupae, separating dead insects, separating large and small insects, sifting sand, peeling, removing impurities, separating insects, and vacuuming.
2. Some functions include: sifting sand, removing skins, removing impurities, and vacuuming (normally breeding worms before 7 years of age generally do not need to separate large and small worms from pupae, dead worms, and adult worms, so in order to save time and improve efficiency, only use This part of the function is sufficient).



Approximate dimensions:	2000*1150*900mm
Material:	Stainless steel + paint
power:	860w
Number of machine operators:	It can be operated by just one person.
Weight	220kg
Voltage:	220V, 50-60HZ.
Separation tape for live and immobile insects:	The speed is adjustable from 0 to 300 pm
Screening vibration intensity:	adjustable size
Vacuum suction wind force:	not adjustable



A. Based on the first eight generations of machines, the ninth-generation machine solves the problem of relatively high damage to pupae, changes the internal screening structure, and changes from the original last selection of pupae to the first selection of pupae to reduce damage to pupae;
B. When improving the separation of live insects and immotile insects, there are some problems with live insects in the immotile insects. The original one-layer separation cloth belt is upgraded to a two-layer separation cloth belt; the flat separation cloth belt is changed to a 20-degree inclined one. The corner design greatly improves the separation effect of live insects and immobile insects, making some old insects more stable than before; the separation belt is lengthened from the original 1 meter to 1.8 meters, which gives more time to the old insects. Catch the live insects and diseased live insects that do not move very much; before, there were about 10%-25% live insects in the immobile insects, but now it can be reduced to about 1%-7%.
c. Improve the large and small insect separation screen. The length of the internal mesh screen is upgraded from the original 1 meter to 1.5 meters, making the large and small insect separation faster, more uniform, and more efficient. D. The casing is changed to a stainless steel casing, which is more resistant to dirt and rust; the machine shell is fixed with screws instead of buckles, making it easier to open the door for maintenance and inspection inside the machine.
