Cotton Opening Machine

This Cotton Opening Machine is equipped with infrared automatic feeding and discharging control, ensuring smooth and precise operation. Its seamless steel-pipe gear system guarantees stability, while the body is built with durable steel plates that meet national standards and finished with electrostatic spraying and baking paint for long-lasting protection. With a production capacity ranging from 50 kg/h to 350 kg/h, the machine also features a 24V control panel and fiber anti-clogging safety devices, delivering high efficiency, reliable safety, and low maintenance costs.

No	Item	Shuliy
1	Capacity	70-80kg/h
2	Voltage	380V/50Hz or220V/50Hz
3	Power	1.5kw
4	Dimension	750*830*900mm
5	Air pressure	0.6-0.8mpa

Feeding Section:
The feeding system is composed of a cotton board wrapped with metallic card clothing, creating a strong grip. To enhance the holding force between the rollers and the cotton board and reduce wear in the opening area, alloy copper plates are embedded at critical positions.

Opening Section:
The high-speed rotating main cylinder works together with the cotton board to thoroughly tear and open the fed material. Depending on the type of scraps used by different customers, the metal card clothing on the main cylinder is precisely designed with strict requirements for tooth density, height, depth, pitch, and angle to ensure optimal performance.

Discharging Section:
The opened fibers are collected at the bottom of the machine and discharged through a powerful fan via the output duct. Additional pipelines can be connected for direct delivery to designated locations.

Boosts Productivity: The cotton opening machine features fast feeding, high output, and an opening rate of over 95%.

Cost-Effective & Space-Saving: Using PP cotton and synthetic fiber as raw materials keeps production costs low while requiring minimal storage space.

Superior Filling Performance: Equipped with advanced 2D and 3D opening technology, the machine protects fiber integrity, prevents knotting, and delivers fluffy, elastic cotton with excellent filling results.
