Box Hydraulic Metal Shearing Machine



The Box Hydraulic Metal Shearing Machine  is an efficient scrap metal cutting machine, widely used in various metal processing enterprises and scrap material recycling industries. With its compact design and easy operation, it is suitable for cutting various metal materials, such as steel, iron sheets, copper, and aluminum alloys. This equipment significantly enhances the efficiency of scrap metal processing, making it an ideal choice for modern metal recycling companies.

The box-type metal shear features a robust box structure design, offering excellent impact resistance. The cutting blades are made from high-strength alloy materials, ensuring a long service life. The machine is equipped with an advanced hydraulic system, guaranteeing stable and efficient cutting operations. Additionally, the shear's control system is user-friendly, allowing operators to quickly adjust cutting parameters through the panel to accommodate different sizes and types of metal materials.



Model	SL-630	SL-800	SL-1000
Material box size(L*W*H)	2667*1600*2000mm	2667*1600*2080mm	2678*2000*2232mm
Feed box size(L*W*H)	3400*2400*900mm	3472*2400*900mm	3830*2800*900mm
Equipment size(L*W*H)	8250*2500*3300mm	8250*2500*3300mm	10250*2500*3300mm
work pressure	21.5MPA	21.5MPA	21.5MPA
Shearing knife length	1600mm	1600mm	2000mm
clipping height	400mm	500mm	50mm
number of cuts	3 t/min	3 t/min	3 t/min
Shear speed	23s/t	23s/t	23s/t
total equipment output	10t-12t/h	15t-20t/h	25t-30t/h
Tips: Other big capacity for industrial production, pls contact sales director for more details







Blade Material: Made from high-strength alloy steel, offering excellent wear resistance and cutting performance.

Box Structure: The machine's box is welded from high-strength steel plates, ensuring stability even under high-load operations.

Hydraulic System: Equipped with a high-performance hydraulic system, providing strong cutting force and adjustable cutting speed to meet different working environments.

Control System: Features a PLC control system with a user-friendly touch screen interface, offering simple operation and multiple safety protection functions.
