Washing Powder Packing Machine

The washing powder packing machine offers fully automated feeding, weighing, packaging, and output functions. Packaging sizes can be customized according to different products and weight requirements. With a user-friendly interface and low operating cost, it is simple to use and maintain. Equipped with a dual-belt film pulling system driven by a servo motor, the machine ensures accurate bag positioning, which can be easily adjusted via the touch screen.

Type	SL-420
Bag length	80-300mm(L)
Bag width	50-200mm(W)
Max width of roll film	420mm
Packing speed	5-60bags/min
Measuring range	150-1200ml
Air consumption	0.65mpa
Gas consumption	0.3m³/min
Power voltage	220V
Power	2.2KW
Dimension	(L)1320mm×(W)950mm×(H)1360mm
Deadweight of machine	540Kg

1. Equipped with a standard set of five measuring cups, the machine is easy to understand and operate.

2. Widely used in the food industry for packaging irregularly shaped or unevenly weighted products.

3. Requires minimal labor, reduces material waste, and offers convenient operation and maintenance.

4. Controlled by a PLC system with a touch-screen interface, making it intuitive and user-friendly.

5. The servo-driven film feeding system ensures precise positioning and neat, attractive packaging.

6 . Integrated with a Z-type bucket elevator and weighing system for fully automated and efficient material handling.

1. The fully automatic granule packing machine is capable of completing the entire process automatically - including material feeding, measuring, filling, bag forming, date printing, heat sealing, and cutting.

2. It adopts a servo motor drive system for stable and precise performance.

3. A high-sensitivity photoelectric sensor system ensures accurate film alignment and consistent bag length during operation.

4. The machine is equipped with an advanced computer control system for reliable and intelligent operation.

5. A constant-temperature heating system maintains precise temperature control within ±1°C, ensuring stable sealing quality.

6. All electrical and pneumatic components are sourced from long-term, trusted suppliers, ensuring both high quality and cost efficiency.

7. Bag size and packing quantity can be customized according to customer requirements.
