Peanut Grading Machine



Peanut grading machine is a dedicated peanut grading equipment, which absorbs the advantages of similar products, and has the advantages of compact and reasonable structure, high efficiency, convenient use, and reliability.



About the peanut grading machine, sprockets and chains are used to drive push rods, and the sieve body performs smooth reciprocating screening. The sieve pieces are made of punched iron plates. There is a return plate at the bottom of each layer of the sieve body, which can make the materials go through the whole process of screening on the sieve pieces. Eliminates the disadvantages of unclear classification caused by materials falling into the lower layer without screening in the middle or at the front end.













Produce name	Peanut grading machine
Model	TZM-3
Capacity	About 600-800kg/h
Power	1.1kw
Voltage	380 V 50hz
Dimension	2.4*0.8*1.6M
Levels:	Three-level







The peanut grading machine can be used not only for peanut grading but also for different nuts such as apricot cores, hazelnuts, almonds, etc., to screen them into three or more grades of large, medium, and small. It is composed of one, two, and three vibrating screens, which can be screened and graded at the same time. The movable screen has a screen hole of 6---10 mm. The screen can be replaced according to different varieties to separate out the qualified size grade. Reasonable design, low breakage rate.



1. Many types of materials can be processed;

2. Can be divided into multiple levels: two layers, three layers, five layers or more, which can be customized according to customers’ demands;

3. The mesh size of the sieve can be customized according to the customer's material and size requirements.
