working principle

The working principle of the colloid mill machine relies on the relative movement of the tooth-shaped slopes of the grinding disc, one of which rotates at a high speed, and the other is stationary, so that the materials passing through the tooth-shaped slopes are subject to very large shearing force and friction force, and at the same time at high frequency Under the action of complex forces such as vibration and high-speed vortex, the materials can be effectively ground, emulsified, pulverized, dispersed and homogenized, so as to obtain fine particle pulverization effect.

The colloid mill machine is not limited to the processing of "colloid" materials, but can also process various fluids, semi-fluids, creams, and even solid soft materials with a certain humidity or oiliness. Crushing, dispersing, emulsifying, and homogenizing treatment have a wide range of applications, and are necessary equipment for processing fine materials in modern industrial production.

colloid mill machine application

Products application

1. Food: sesame paste, peanut butter, ketchup, chili sauce, red bean paste, ice cream, cream, food additives, etc.

2. Beverages: various juice drinks, protein drinks, dairy drinks, fruit tea, jelly, etc.

3. Medicine: oral liquid, syrup, royal jelly, Chinese patent medicine, ointment, etc.

4. Daily chemicals: laundry detergent, hand sanitizer, shampoo, shower gel, toothpaste, soap, etc.

5. Chemical industry: emulsified asphalt, paint, coating, dye, lubricating oil, grease, adhesive, etc.

6. Colloid mill machine can also be used in the construction industry, plastics industry, textile industry, paper industry, nanomaterials, and many other industries.

colloid mill machine structure

Products advantage

1. The grinding fineness can be adjusted within the range of 0.1-5mm

2. The colloid mill motor adopts frequency conversion control, the current impact is small, and the speed can be adjusted according to the product

3. Core components such as fixed teeth and rotating gears are anti-corrosion and anti-wear (experimental life exceeds 200,000 tons)

4. The colloid mill machine has small volume, low energy consumption, stable performance, convenient operation and simple maintenance

5. Customized production according to customer needs, All types of grinding machines reserve external interfaces, which can expand functions and output

colloid mill machine details

Products parameter

Model	TZ-130	TZ-180	TZ-210
Output	20-70 Micro	20-70 Micro	20-70 Micro
Capacity	About 200-300kg/h	500-800kg/h	800-1000kg/h
Power	11kw	30kw	37kw
Weight	240kg	300kg	550kg
Size (mm)	1000x350x1000mm	1200x450x1200mm	1200x500x1200mm
