Products Description
Chili destemming machine Working principle:
The peppers are fed from the feed port through the arc guide and then fall into the drum. The drum rotates at a high speed. The pepper handles extend out of the gap in the drum mesh and are cut off by several sets of stainless steel blades with different orientations, completing the removal process. The drum has a certain slope, and the peppers move forward while rolling, and finally fall out of the drum and are discharged smoothly. There is a guide eccentric orifice plate inside the drum, which controls the speed and arrangement of the materials without damaging them.
Products application
Products details
It mainly consists of a feeding system, bracket, roller, cutting system, power system, and other components. Can be customized specifically for different types of peppers.
advantage:
The Chili destemming machine is simple to operate: only one person needs to pour the peppers. The machine is simple to use and easy to maintain. It can realize automatic diversion of finished products and waste materials. With the shortage of labor and the increase in labor costs, the mechanization of pepper removal is The key to solving the problem. It is very suitable for large, medium, and small enterprises, farmers, pepper processing plants, etc.
Products parameters
|
Chili stem-cutting machine |
||
|
model |
picture |
parameter |
|
TZ-50-2A (Double barrel machine)
|
|
Voltage:220v 50hz,1 phase Power:3kw Size:2860*590*1360mm Weight:238kg Material: carbon steel Capacity: Dry chili:120kg/h Wet chili:250kg/h |
|
TZ-50-2S (Stainless steel double barrel machine) |
|
Voltage:220v 50hz,1 phase Power:3kw Size:2860*590*1360mm Weight:252kg Material:304 stainless steel Capacity: Dry chili:120kg/h Wet chili:250kg/h |
|
TZ-50-2ALT (Double cylinder lengthening machine) |
|
Voltage:220v 50hz,1 phase Power:3kw Size:3860*590*1360mm Weight:357kg Material: carbon steel Capacity: Dry chili:180kg/h Wet chili:330kg/h |
|
TZ-50-2SLT (Stainless steel double barrel lengthening machine) |
|
Voltage:220v 50hz,1 phase Power:3kw Size:3860*590*1360mm Weight:362kg Material:304 stainless steel Capacity: Dry chili:180kg/h Wet chili:330kg/h |
|
TZ-50-2ABIGS (Four drum machine) |
|
Voltage:220v 50hz,1 phase Power:4.4kw Size:2860*1100*1500mm Weight:470kg Material: carbon steel Capacity: Dry chili:250kg/h Wet chili:500kg/h |
|
TZ-50-2SBIGS (Stainless steel four drum machine) |
|
Voltage:220v 50hz,1 phase Power:4.4kw Size:2860*1100*1500mm Weight:482kg Material:304 stainless steel Capacity: Dry chili:250kg/h Wet chili:500kg/h |
|
TZ-70W-2ATL (48 cm drum machine) |
|
Voltage:220v 50hz,1 phase Power:4.4kw Size:3860*680*1600mm Weight:476kg Material: carbon steel Capacity: Dry chili:220kg/h Wet chili:400kg/h |
|
TZ-70W-2ANF (48 cm drum machine) |
|
Voltage:220v 50hz,1 phase Power:4.4kw Size:4860*680*1650mm Weight:550kg Material: carbon steel Capacity: Dry chili:350kg/h Wet chili:700kg/h |
