Products Description
The raw material of the dry ice granule machine is liquid CO2. When the machine works, it needs to be connected to a CO2 storage tank so that the machine can operate normally. Final dry ice granules could be 3mm-19mm and can change different sizes mold to get different size dry ice pellets.
Products specification
|
Model |
SL-50 |
SL-100 |
SL-200 |
|
Power(kW) |
3 |
5.5 |
11 |
|
Dry ice specification (mm) |
Φ3-Φ16 |
Φ3-Φ19 |
Φ3-Φ19 |
|
Capacity (kg/h) |
50 |
100 |
180-200 |
|
The density of dry ice(t/m³) |
≥1.48 |
≥1.48 |
≥1.50 |
|
CO 2 conversion rate |
40%-43.5% |
40%-43.5% |
40%-43.5% |
|
Fluid enter pressure (Mpa) |
≤2.1 |
≤2.1 |
≤2.1 |
|
Fluid enters inner diameter (mm) |
Φ 8 |
Φ 10 |
Φ 20 |
|
Exhaust pipe diameter (mm) |
Φ 50 |
Φ 50 |
2×Φ 50 |
|
Fuel tank capacity (L) |
100 |
180 |
280 |
|
Weight (kg) |
400 |
750 |
1300 |
|
Dimension (mm) |
1100*600*1200 |
1500*800*1400 |
1750*1100*1700 |
application
Granule dry ice pellet making machine, this is a super small volume, energy-saving, safe, mobile ice machine; High mechanical manufacturing accuracy, advanced control system, software, and high precision measurement make this series of dry-ice granule machines widely used in dry ice cleaning, low temperature preservation and cold chain transportation, smoke effect, laboratory and other industries.
advantage
1. This Commercial Dry Ice Machine is made of stainless steel, durable in use.
2. The dry ice production of dry ice making machine is mainly suitable for dry ice cleaning, preservation, and transportation at low temperatures, stage fog, etc.
3. Fully automatic control of oil temperature and dry ice snowing process guarantees continuous dry ice production without any supervision right from push button start.
4. PLC Omron - controls the complete process, injection, and hydraulic Independent performance - very constant production, independent of pressure and temperature
5. Integrated production control system- definition and supervision of production quantity
6. High process reliability - optimized process monitoring provides optimal performance and increases process reliability
7. Easy maintenance - simple structure and easy replacement of spare parts make maintenance work simple for even new users
8. Minimum floor space for high-production performance
